AbstractSurface#

class optika.surfaces.AbstractSurface[source]#

Bases: DxfWritable, Plottable, Printable, Transformable, Shaped, AbstractLightPropagator, Generic[SagT, MaterialT, ApertureT, ApertureMechanicalT, RulingsT]

Interface describing a single optical interface.

Attributes

`aperture`	The region of this surface which allows light to propagate.
`aperture_mechanical`	The shape of the physical substrate containing this optical surface.
`is_field_stop`	A flag controlling whether this surface should act as the field stop for the system
`is_pupil_stop`	A flag controlling whether this surface should act as the pupil stop for the system
`is_stop`	If this surface is pupil stop or the field stop, return `True`.
`kwargs_plot`	Extra keyword arguments that will be used in the call to `named_arrays.plt.plot()` within the `plot()` method.
`material`	The optical material type of this surface.
`name`	The human-readable name of this surface.
`rulings`	The optional ruling profile of this surface.
`sag`	The sag profile of this surface.
`shape`	The array shape of this object.
`transformation`	the coordinate transformation between the global coordinate system and this object's local coordinate system

Methods

`__init__`()
`plot`([ax, transformation, components])	Plot the selected components onto the given axes.
`propagate_rays`(rays)	Refract, reflect, and/or diffract the given rays off of this surface
`to_dxf`(file, unit[, transformation])
`to_string`([prefix])	Public-facing version of the `__repr__` method that allows for defining a prefix string, which can be used to calculate how much whitespace to add to the beginning of each line of the result.

Inheritance Diagram

plot(ax=None, transformation=None, components=None, **kwargs)[source]#

Plot the selected components onto the given axes.

Parameters:

ax (None | Axes | ScalarArray[ndarray[tuple[Any, ...], dtype[_ScalarT]]]) – The matplotlib axes to plot onto
transformation (None | AbstractTransformation) – Any extra transformations to apply to the coordinate system before plotting
components (None | tuple[str, ...]) – Which 3d components to plot, helpful if plotting in 2d.
kwargs – Additional keyword arguments that will be passed along to named_arrays.plt.plot()

Return type:

dict[str, AbstractScalar]

propagate_rays(rays)[source]#

Refract, reflect, and/or diffract the given rays off of this surface

Parameters:: rays (RayVectorArray) – a set of input rays that will interact with this surface
Return type:: RayVectorArray

to_dxf(file, unit, transformation=None)#

Parameters:

file (Path)
unit (Unit)
transformation (None | AbstractTransformation)

to_string(prefix=None)#

Public-facing version of the __repr__ method that allows for defining a prefix string, which can be used to calculate how much whitespace to add to the beginning of each line of the result.

Parameters:: prefix (None | str) – an optional string, the length of which is used to calculate how much whitespace to add to the result.
Return type:: str

abstract property aperture: ApertureT#: The region of this surface which allows light to propagate.

abstract property aperture_mechanical: ApertureMechanicalT#: The shape of the physical substrate containing this optical surface.

abstract property is_field_stop: bool#: A flag controlling whether this surface should act as the field stop for the system

abstract property is_pupil_stop: bool#: A flag controlling whether this surface should act as the pupil stop for the system

property is_stop: bool#: If this surface is pupil stop or the field stop, return True.

abstract property kwargs_plot: None | dict#: Extra keyword arguments that will be used in the call to named_arrays.plt.plot() within the plot() method.

abstract property material: MaterialT#: The optical material type of this surface.

abstract property name: str#: The human-readable name of this surface.

abstract property rulings: RulingsT#: The optional ruling profile of this surface.

abstract property sag: SagT#: The sag profile of this surface.

abstract property shape: dict[str, int]#: The array shape of this object.

abstract property transformation: None | AbstractTransformation#: the coordinate transformation between the global coordinate system and this object’s local coordinate system
