AbstractImagingSensor#

class optika.sensors.AbstractImagingSensor[source]#

Bases: AbstractSurface[None, MaterialT, RectangularAperture, RectangularAperture, None]

An interface describing an imaging sensor that can be used as the last surface in an optical system.

Attributes

`aperture`	The light-sensitive aperture of the sensor.
`aperture_mechanical`	The shape of the physical substrate containing this optical surface.
`axis_pixel`	The names of the logical axes corresponding to the rows and columns of the pixel grid.
`is_field_stop`	A flag controlling whether this surface should act as the field stop for the system
`is_pupil_stop`	A flag controlling whether this surface should act as the pupil stop for the system
`is_stop`	If this surface is pupil stop or the field stop, return `True`.
`kwargs_plot`	Extra keyword arguments that will be used in the call to `named_arrays.plt.plot()` within the `plot()` method.
`material`	The optical material type of this surface.
`name`	The human-readable name of this surface.
`num_pixel`	The number of pixels along each axis of the sensor.
`rulings`	The optional ruling profile of this surface.
`sag`	The sag profile of this surface.
`shape`	The array shape of this object.
`timedelta_exposure`	The exposure time of the sensor.
`transformation`	the coordinate transformation between the global coordinate system and this object's local coordinate system
`width_pixel`	The physical size of each pixel on the sensor.

Methods

`__init__`()
`plot`([ax, transformation, components])	Plot the selected components onto the given axes.
`propagate_rays`(rays)	Refract, reflect, and/or diffract the given rays off of this surface
`readout`(rays, wavelength[, timedelta, axis, ...])	Given a set of rays incident on the sensor surface, where each ray represents an expected number of photons per unit time, simulate the number of electrons that would be measured by the sensor.
`to_dxf`(file, unit[, transformation])
`to_string`([prefix])	Public-facing version of the `__repr__` method that allows for defining a prefix string, which can be used to calculate how much whitespace to add to the beginning of each line of the result.

Inheritance Diagram

plot(ax=None, transformation=None, components=None, **kwargs)#

Plot the selected components onto the given axes.

Parameters:

ax (None | Axes | ScalarArray[ndarray[tuple[Any, ...], dtype[_ScalarT]]]) – The matplotlib axes to plot onto
transformation (None | AbstractTransformation) – Any extra transformations to apply to the coordinate system before plotting
components (None | tuple[str, ...]) – Which 3d components to plot, helpful if plotting in 2d.
kwargs – Additional keyword arguments that will be passed along to named_arrays.plt.plot()

Return type:

dict[str, AbstractScalar]

propagate_rays(rays)#

Refract, reflect, and/or diffract the given rays off of this surface

Parameters:: rays (RayVectorArray) – a set of input rays that will interact with this surface
Return type:: RayVectorArray

readout(rays, wavelength, timedelta=None, axis=None, where=True, noise=True)[source]#

Given a set of rays incident on the sensor surface, where each ray represents an expected number of photons per unit time, simulate the number of electrons that would be measured by the sensor.

Parameters:

rays (RayVectorArray) – A set of incident rays in local coordinates to measure.
wavelength (AbstractScalar) – The edges of the wavelength bins to sample.
timedelta (None | Quantity | AbstractScalar) – The exposure time of the measurement. If None (the default), the value in timedelta_exposure will be used.
axis (None | str | Sequence[str]) – The logical axes along which to collect photons.
where (bool | AbstractScalar) – A boolean mask used to indicate which photons should be considered when calculating the signal measured by the sensor.
noise (bool) – Whether to add noise to the result

Return type:

FunctionArray[SpectralPositionalVectorArray, AbstractScalar]

to_dxf(file, unit, transformation=None)#

Parameters:

file (Path)
unit (Unit)
transformation (None | AbstractTransformation)

to_string(prefix=None)#

Public-facing version of the __repr__ method that allows for defining a prefix string, which can be used to calculate how much whitespace to add to the beginning of each line of the result.

Parameters:: prefix (None | str) – an optional string, the length of which is used to calculate how much whitespace to add to the result.
Return type:: str

property aperture#: The light-sensitive aperture of the sensor.

abstract property aperture_mechanical: ApertureMechanicalT#: The shape of the physical substrate containing this optical surface.

abstract property axis_pixel: Cartesian2dVectorArray[str, str]#: The names of the logical axes corresponding to the rows and columns of the pixel grid.

abstract property is_field_stop: bool#: A flag controlling whether this surface should act as the field stop for the system

abstract property is_pupil_stop: bool#: A flag controlling whether this surface should act as the pupil stop for the system

property is_stop: bool#: If this surface is pupil stop or the field stop, return True.

abstract property kwargs_plot: None | dict#: Extra keyword arguments that will be used in the call to named_arrays.plt.plot() within the plot() method.

abstract property material: MaterialT#: The optical material type of this surface.

abstract property name: str#: The human-readable name of this surface.

abstract property num_pixel: Cartesian2dVectorArray[int, int]#: The number of pixels along each axis of the sensor.

property rulings: None#: The optional ruling profile of this surface.

property sag: AbstractSag#: The sag profile of this surface.

abstract property shape: dict[str, int]#: The array shape of this object.

abstract property timedelta_exposure: Quantity | AbstractScalar#: The exposure time of the sensor.

abstract property transformation: None | AbstractTransformation#: the coordinate transformation between the global coordinate system and this object’s local coordinate system

abstract property width_pixel: Quantity | AbstractCartesian2dVectorArray#: The physical size of each pixel on the sensor.
